Hydraulic Cylinder
Product Overview
Hydraulic cylinder is the core executive component of hydraulic systems, converting hydraulic pressure into linear mechanical force and motion. Our company supplies a full range of high-performance hydraulic cylinders, including welded hydraulic cylinders, tie-rod cylinders, telescopic cylinders, double-acting and single-acting cylinders. Strictly manufactured in accordance with international industrial standards, all products feature stable performance, high precision, strong pressure resistance and long service life, widely applicable to engineering machinery, industrial equipment, agricultural machinery and marine facilities. We support OEM & ODM customized services to meet diverse working condition requirements of global customers.
Core Features & Advantages
Premium Material & Durable Structure: Adopts high-strength seamless steel tube cylinder barrel and high-precision solid piston rod, with overall forging and thickened welding process. The product resists deformation and wear under high pressure and heavy load, adapting to harsh working environments such as dust, humidity and high temperature.
High-Precision Sealing System: Equipped with imported high-density sealing components, featuring excellent oil resistance, wear resistance and aging resistance. It effectively prevents oil leakage, ensures no leakage during long-term continuous operation, and reduces equipment failure rate and maintenance costs.
Stable & Efficient Operation: Precision machining of inner cylinder wall and piston rod surface ensures smooth telescopic movement, low friction resistance and high transmission efficiency. The built-in buffer device avoids impact and noise during operation, realizing stable and quiet linear movement.
Strong Pressure & Load Resistance: Standard working pressure reaches up to 35MPa, with customized high-pressure models available. It can stably bear heavy loads and maintain consistent working performance under long-time high-intensity operation.
Easy Installation & Maintenance: Multiple standard mounting methods are optional, with simple and reasonable structural design. The disassembly and maintenance process is convenient, greatly shortening equipment downtime and improving overall operation efficiency.
Strict Quality Inspection: All products undergo 100% full-pressure testing, sealing performance testing and durability testing before delivery, with stable quality and compliance with CE and other international certification standards.
 |
 |
Standard Technical Parameters
We provide standardized and customized hydraulic cylinders with complete specifications to cover different industrial needs. The core parameters are as follows:
| Parameter Item | Standard Specification |
| Working Pressure | Max 35MPa (Customizable high pressure) |
| Bore Diameter | 20mm - 500mm |
| Rod Diameter | 10mm - 360mm |
| Stroke Length | Max 6000mm |
| Operation Mode | Single-acting / Double-acting |
| Mounting Type | Clevis, Flange, Trunnion, Tie-rod |
| Surface Treatment | Hard chrome plating, anti-rust spraying |
| Certification | CE, ISO9001 / CE、ISO9001 |
Product Classification
Welded Hydraulic Cylinder: Integrated welded structure, high strength and impact resistance, widely used in excavators, loaders, road rollers and other construction machinery.
Tie-Rod Hydraulic Cylinder: Simple structure, easy disassembly and maintenance, cost-effective, suitable for general industrial machinery and agricultural equipment.
Telescopic Hydraulic Cylinder: Multi-stage telescopic design, small retracted size and long stroke, ideal for dump trucks, tippers and lifting equipment.
Custom Special Cylinder: Customized according to customer drawings, samples and working conditions, including high-pressure, ultra-long stroke, corrosion-resistant and marine-specific cylinders.
 |
 |
Application Scenarios
Our hydraulic cylinders are widely exported to Europe, America, Southeast Asia, Middle East and other global markets, serving multiple industries:
Construction Machinery: Excavators, loaders, bulldozers, road rollers, cranes, aerial work platforms
Agricultural Machinery: Tractors, harvesters, agricultural lifting and folding equipment
Industrial Equipment : Hydraulic presses, injection molding machines, lifting platforms, automated production lines
Special Machinery : Dump trucks, sanitation vehicles, marine equipment, mining machinery
Our Service
Customization Service: Support non-standard customization of size, pressure, stroke, installation method and surface treatment.
Quality Assurance: 12-month warranty, full-process quality traceability, strict inspection before shipment.
Export Support: Familiar with international trade processes, provide CE certification, packing list, invoice, bill of lading and other full export documents.
Global Logistics: Support sea freight, air freight and express delivery, stable supply and fast delivery.
Technical Support: Provide professional one-stop pre-sales consultation and after-sales technical guidance.
